| PMDC MOTOR Technical Data | |||||||||||
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed | Current | Speed | Current | Torque | Power | Current | Torque | ||
| RPM | A | RPM | A | mN.m / gf.cm | W | A | mN.m / gf.cm | ||||
| RS-770H | 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81/826.2 | 111.8 | 115 | 666.9/6802 |
| RS-775H | 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4/452.9 | 13.35 | 4.07 | 245.7/2506 |
We are a factory specialized in producing motors for more than 14 years. With three factories, a professional R&D team, mature management, and an experienced engineering and sales team, we ensure a pleasant experience.
To ensure premium quality, every step from raw material inspection to final shipment is carefully checked. Quality is the foundation of our development.
We are gold seller and in possession of high credibility.
100% on-time delivery rate confirms your product arrives timely.
Standard samples will be produced within 2 weeks. Customized samples will be produced within 3 weeks.
Timely reply: your message will be replied within 2 hours.
We are a factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
We can draw up an Ali Assurance Order online for our new customers, which can be paid online with Master Card, Visa, etc. Customers can also pay with PayPal, TT, etc.
Yes, we can customize a suitable motor according to our customers' specific requirements.
Yes, we have CE, FCC, ISO, etc. If you have other specific certificate requirements, we can apply for them.
We have professional checking staff for every production line process. Once the motor is complete, we utilize specialized testing equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, Noise Testers, and more.
Standard samples are produced within 2 weeks, while customized samples are completed within 3 weeks.
