| PMDC MOTOR Technical Data | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | Rated Voltage (V) | No-Load | Rated | Stall | |||||||
| Operating Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m / gf.cm) | Power (W) | Current (A) | Torque (mN.m / gf.cm) | ||
| RS-770H | 8523R | 6.0~12.0 | 12 VDC | 15000 | 2.2 | 13177 | 15.91 | 81/826.2 | 111.8 | 115 | 666.9/6802 |
| RS-775H | 25110R | 6.0~24.0 | 24 VDC | 3478 | 0.15 | 2925 | 0.75 | 44.4/452.9 | 13.35 | 4.07 | 245.7/2506 |
1. Are you a trading company or a manufacturer?
We are a factory. We specialize in micro DC motors and DC gear motors with over 14 years of industry experience.
2. What is the payment term for new customers?
We can establish an Online Assurance Order for new customers, supporting online payments via MasterCard, Visa, PayPal, or TT bank transfers.
3. Can you customize a motor if I cannot find a suitable one on your website?
Yes, we can customize a suitable motor configured exactly to our customer's specific technical requirements.
4. Do you have quality certificates for the motors?
Yes, we have CE, FCC, ISO, and other relevant certifications. If you have additional certification requirements, we can apply for them.
5. How do you handle Quality Control?
We employ professional inspection staff on every production line process. Finished motors undergo thorough verification using dedicated machinery, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.
6. Can the motor shaft length be customized?
Yes, the length of the shaft can be customized according to your specific configuration requirements.
