KINOV Motor
1 / 5
| MODEL | RATED | NO LOAD | RATED | STALL | ||
|---|---|---|---|---|---|---|
| VOLTAGE (V) | SPEED (r/min) | CURRENT (mA) | SPEED (r/min) | CURRENT (mA) | CURRENT (mA) | |
| 0724 | 1.5 | 19900 | 45 | 17600 | 108 | 480 |
| 0724 | 5 | 20000 | 33 | 18500 | 65 | 400 |
| 0724 | 3 | 25300 | 28 | 21300 | 89 | 370 |
A1: The 0724 model motor is available in rated voltages of 1.5V, 3V, and 5V to support different power requirements.
A2: The maximum no-load speed reaches up to 25,300 r/min when operated under the 3V configuration.
A3: Under standard rated operating conditions, the 5V variant draws a low rated current of 65 mA.
A4: The stall current for the 1.5V model configuration is rated at 480 mA.
A5: These compact DC brush motors are commonly engineered for adult toys, personal vibrators, mini electrical appliances, and lightweight portable electronics requiring mini vibration motors.
A6: Under typical load conditions, the 3V motor model operates at a rated speed of approximately 21,300 r/min.
