Shunli Custom Professional Manufacturer Hair Dryer and Micro Vacuum Cleaner 390PH 12v Dc Motor Brush Brushless

1 / 5

Shunli Custom Professional Manufacturer Hair Dryer and Micro Vacuum Cleaner 390PH 12v Dc Motor Brush Brushless

Send Inquiry

Product Description

Professional Manufacturer Hair Dryer and Micro Vacuum Cleaner 390PH 12v Dc Motor Brush Brushless

Product Description

Professional manufacturer hair dryer and micro vacuum cleaner 390PH 12v dc motor

Product Details

Motor Customized Specification

Reference Drawing

------ RS - 365

------ RS - 385

------ RS - 395

The length of shaft can be customized

Reference Datasheet

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-390SH	20156R	6.0~12.0	12VDC	5000	0.08	4243	0.33	6.07 / 61.9	2.72	2.22	42.2 / 430
RS-390SH	2975	6.0~12.0	12VDC	12000	0.29	10165	0.33	5.75 / 58.6	1.31	8.9	80.4 / 820
RS-395SH	15130	6.0~12.0	12VDC	3650	0.66	2949	0.25	5.83 / 59.5	1.8	1.06	30.4 / 310
RS-395SH	15100R	6.0~24.0	24VDC	10300	0.07	8893	0.38	7.09 / 72.3	6.68	2.66	54.9 / 560

Recommend Product

Frequently Asked Questions (FAQ)

What applications are the 390PH series DC motors suitable for?

The 390PH series DC motors are professionally designed and highly optimized for hair dryers, micro vacuum cleaners, and other high-efficiency household appliances.

Can the motor shaft length and specifications be customized?

Yes. We support custom modifications for both the motor shaft length and the technical specifications based on your specific application requirements.

What is the operating voltage range of the RS-390SH motor?

The operating voltage range for both RS-390SH models is 6.0V to 12.0V DC, with a nominal testing voltage at 12VDC.

What is the no-load speed performance of the RS-390SH (2975) model?

The RS-390SH (2975) model achieves a high no-load speed of 12,000 RPM at a nominal voltage of 12VDC, with a low no-load current of 0.29A.

How does the RS-395SH (15100R) compare to other models in voltage and speed?

The RS-395SH (15100R) operates over a wider voltage range of 6.0V to 24.0V, with a nominal voltage of 24VDC, achieving a no-load speed of 10,300 RPM.

What stall torque parameters do these PMDC motors offer?

Stall torque varies by model: RS-390SH offers up to 80.4 mN.m (820 gf.cm) for the 2975 variant, while RS-395SH offers up to 54.9 mN.m (560 gf.cm) for the 15100R variant.
