SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

1 / 4

SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98 / 10	0.1	260	4.02 / 41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4 / 24.5	1.71	2550	17 / 173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2 / 73.4	11.51	24000	55 / 561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8 / 59.2	5.17	3800	37.5 / 382.5

Click on the tilt font to know more parameters!

Application

Frequently Asked Questions

What are the electrical specifications for the SRC-370SH-4730 motor?

The SRC-370SH-4730 operates at a nominal voltage of 4.5V VDC (with an operating range of 3.0V to 5.0V). It features a no-load speed of 17,500 RPM, a rated power output of 11.51W, and a rated current of 3,630 mA.

What is the operating voltage range of the RC-370 series motors?

The operating voltage range depends on the specific model: the RC-370CH operates between 3.0V and 6.0V VDC, the RC-370SH-4730 operates between 3.0V and 5.0V VDC, and the RC-370SH-18139 operates between 6.0V and 12.0V VDC.

Which RC-370 model offers the highest no-load speed?

The RC-370SH-4730 model provides the highest no-load speed in the series, reaching 17,500 RPM under a nominal voltage of 4.5V VDC.

What are the stall characteristics of the RC-370SH-18139 motor?

At a nominal voltage of 12 VDC, the RC-370SH-18139 has a stall current of 3,800 mA and a stall torque of 37.5 mN.m (equivalent to 382.5 gf.cm).

What is the rated power of the RC-370CH motor?

The RC-370CH model features a rated power of 1.71W under a nominal voltage of 6 VDC, with a rated speed of 6,878 RPM and a rated current of 420 mA.

Product Detail

SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Product Description
